Service & Repair Kits
Series W65 Replacement Pilot
Assembly & Coil
Description Model Number
Pilot Assembly 1149C79
Coil 334B33
Specify Voltage and Hz when ordering.
Valve Bolt Kits
Valve Size Kit Number
Size 00 RPS5687P
Size 0 RPS5587P
Quantity 12
Manifold Hardware Kits
Valve Size Kit Number
Size 00 RPS5612P
Size 0 RPS5512P
Size 1 RPS4012P
Size 2 RPS4112P
Size 3 RPS4212P
Quantity 12
Regulator Kits
Valve Size Kit Number
Size 1 RPS4039P
Size 2 & 3 RPS4139P
Pilot Select Gasket Kits
Valve Size Kit Number
Size 00 RPS5605P
Size 0 RPS5505P
Quantity 10
Indicates External Pilot Indicates Internal Pilot
Size 00 Shown
Manifold to Manifold Gasket Kits
15407-2
Size Standard
Blocked
#1 Port
Blocked
#1, 3, 5 Ports
Blocked
#3, 5 Ports
Size 00
RPS561AP RPS561BP RPS561CP RPS561DP
Size 0
Size 1 RPS4013P — — —
Size 2 RPS4113P — — —
Size 3 RPS4213P — — —
RPS561AP RPS561CP RPS561DP RPS561BP
Valve Size Standard
Size 00 RPS5605P*
Size 0 RPS5505P*
Size 1 797B11
Size 2 828B11
Size 3 858B11
Quantity 1, * Quantity 10.
Valve to Base Gasket Kits
Regulator & Flow Control Mounting Studs
Type Size 00 Size 0
Flow Control RPS5636P RPS5536P
Regulator RPS5636P RPS5536P
Type Size 1 Size 2 Size 3
Flow Control RPS4036P RPS4136P RPS4236P
Regulator RPS4040P RPS4140P RPS4240P
Quantity 12
Regulator Gauge Kits – Size 1, 2 & 3
Gauge Type Kit Number
3/4" Face Air - Standard
0-60 PSIG RPS4051060BP
0-160 PSIG RPS4051160BP
1-1/2" Face Air - Large*
0-60 PSIG RPS4053060BP
0-160 PSIG RPS4053160BP
1-1/2" Face Liquid*
0-160 PSIG RPS4052160BP
* Includes brass pipe fitting extensions
Quantity 1
Body Service Kits
Kit Includes: Spool assembly with seals, all piston seals, return spring, pilot selector
gasket, coil to end cap gasket.
Quantity 1
Valve
Size
2
Position
Single
2
Position
Double
3-Position
Closed
Center
Open
Center
Power
Center
Size 00 RPS5601P RPS5601P RPS5602P RPS5603P RPS5604P
Size 0 RPS5501P RPS5501P RPS5502P RPS5503P RPS5504P
Size 1 1422K77 1423K77 1424K77 1425K77 1424K77
Size 2 1467K77 1468K77 1469K77 1470K77 1469K77
Size 3 1471K77 1472K77 1473K77 1474K77 1473K77
