WAFER-LX Motherboard
Page 56
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
25 R0 26 R1
26 R2 28 R3
29 R4 30 R5
31 R6 32 R7
33 GND 34 GND
35 CLK 36 VSYNC
37 LCD_EN 38 HSYNC
39 NC 40 DISP_EN
Table 4-24: TFT LCD TTL Port Connector Pinouts
4.2.22 Internal USB Connectors
CN Label: CN24
CN Type: 8-pin header (2x4)
CN Location: See Figure 4-24
CN Pinouts: See Table 4-25
The 2x4 USB pin connector provides connectivity to two USB 2.0 devices. The USB ports
are used for I/O bus expansion.
