WAFER-LX Motherboard
Page 7
Specification WAFER-LX
SSD CompactFlash®
Super I/O W83627EHG
Audio AC'97 Codec Realtek ALC203
LAN 10/100 Base-T dual RTL8100C
COM
Two RS-232
One RS-422/485
USB2.0 Four USB 1.1 or USB 2.0 devices supported
IDE One 44-pin IDE connects to two Ultra ATA33/66/100 devices
Floppy One floppy disk drive connector
Parallel Port One LPT port connector
SATA Two SATA connectors with transfer rates up to 150 Mb/sec
KB/MS One on-board keyboard/mouse connector
Watchdog Timer Software programmable 1-255 sec. by supper I/O
Digital I/O One GPIO connector
Fan connector One CPU fan connector
Expansion One PC/104 slot
Power Supply
+5 V ± 5% AT/ATX power support
(12 V only necessary for LCD power)
Temperature 0ºC - 60ºC
Humidity (operating) 5%~95% non-condensing
Dimensions 145 mm x 102 mm
Weight (GW/NW) 670g/230g
Table 1-2: Technical Specifications
