WAFER-LX Motherboard

Page 48

CN Location:

See Figure 4-17

CN Pinouts:

See Table 4-18

The PC/104 power input connector provides power to the PC/104 expansion module

installed on the PC/104 slot.

Figure 4-17: PC/104 Power Input Connector Pinouts

PIN NO. DESCRIPTION

1 -5

V

2 GND

3 -12

V

Table 4-18: PC/104 Power Input Connector Pinouts

4.2.16 PC/104 Slot

CN Label:

CN10

CN Type:

104-pin PC/104 slot

CN Location:

See Figure 4-18
