Page 78: Figure 4-23: vga connector, 7 s o ftwa re in s ta lla tio n

641/20/2012165

P a g e 64

IMBA-G410 ATX Mo th e rb o a rd

Figure 4-23: VGA Connector

S te p 4:

Secure the connector. Secure the DB-15 VGA connector from the VGA

monitor to the external interface by tightening the two retention screws on either

side of the connector.

S te p 0:

4.7 S o ftwa re In s ta lla tio n

All the drivers for the IMBA-G410 are on the CD that came with the system. To install the

drivers, please follow the steps below.

S te p 1:

Insert the CD into a CD drive connected to the system.

NOTE:

If the installation program doesn't start automatically:

Click "Start->My Computer->CD Drive->autorun.exe"

S te p 2:

The driver main menu appears.

S te p 3:

Click IMBA-G410.

S te p 4:

A new screen with a list of available drivers appears.

S te p 5:

Install all of the necessary drivers in this menu.

Step 0:
