P a g e 8
IMBA-G410 ATX Mo th e rb o a rd
Fa n c o n n e c to r One 4-pin wafer for CPU fan
Three 3-pin wafer for system fans
Ke yb o a rd /Mo u s e Two external PS/2 connectors
S e ria l P o rts Five RS-232 COM connectors
One RS-232/422/485 COM connector with auto flow control
US B 2.0/1.1 p o rts Four internal via pin header
Four external USB ports
In fra re d One infrared connector via 5-pin header
P a ra lle l P o rt One external parallel port
S e ria l ATA Four independent SATA channels with 3.0 Gb/s data transfer
rates
IDE One 40-pin IDE connector
Co m p a c tFla s h ® One CF Type II slot
S MBu s One 4-pin wafer SMBus connector
TP M One TPM module connector via 20-pin header
En viro n m e n ta l a n d P o we r S p e c ific a tio n s
P o we r S u p p ly ATX power supported
P o we r Co n s u m p tio n 5 V @ 5.45 A
12 V @ 4.80 A
3.3 V @ 0.16 A
-12 V @ 0.06 A
(2.83 GHz Intel® Core™2 Quad Q9550 with 2 GB 1333 MHz
DDR3 DIMM)
Op e ra tin g te m p e ra tu re -10ºC ~ 60ºC, requires cooler and silicone heat sink paste
Hu m id ity 5% ~ 95% (non-condensing)
P h ys ic a l S p e c ific a tio n s
Dim e n s io n s 305 mm x 244 mm
We ig h t (Gro s s /Ne t) 1200 g / 750 g
Table 1-1: Technical Specifications
