P a g e 126

IMBA-G410 ATX Mo th e rb o a rd

C.2.5 Cre a te Fa c to ry De fa u lt Im a g e

NOTE:

Before creating the factory default image, please configure the system

to a factory default environment, including driver and application

installations.

To create a factory default image, please follow the steps below.

S te p 1:

Turn on the system. When the following screen displays (Figure C-10), press

the <F3> key to access the recovery tool. The message will display for 10

seconds, please press F3 before the system boots into the operating system.

Figure C-10: Press F3 to Boot into Recovery Mode

S te p 2:

The recovery tool menu appears. Type <4> and press <Enter>. (Figure C-11)

Figure C-11: Recovery Tool Menu

S te p 3:

The About Symantec Ghost window appears. Click OK button to continue.
