IMBA-G410 ATX Mo th e rb o a rd
P a g e 99
automatically when the computer system boots up. This allows
the immediate use of the 10-key numeric keypad located on
the right side of the keyboard. To confirm this, the Number
Lock LED light on the keyboard is lit.
 Boot From LAN Support [Dis a ble d]
The Boot From LAN Support option enables the system to be booted from a remote
system.

Disabled D EFAULT Cannot be booted from a remote system through the
LAN.

Enabled Can be booted from a remote system through the
LAN.
5.6 S e c u rity
Use the Security menu (BIOS Menu 17) to set system and user passwords.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
Security Settings

Supervisor Password :Not Installed
User Password :Not Installed
Change Supervisor Password
Change User Password
Install or Change the
password.
 Select Screen
↑ ↓ Select Item
Enter Change
F1
General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 17: Security
 Cha nge Supe rvis or Pa s s word
Use the Change Supervisor Password to set or change a supervisor password. The
default for this option is Not Installed. If a supervisor password must be installed, select
