IMBA-G410 ATX Mo th e rb o a rd
3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
Audio connector 10-pin header FP_AUDIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 3-pin wafer SYS_FAN1,
SYS_FAN2,
SYS_FAN3
CPU power input connector 4-pin connector CPU12V1
Digital I/O connector 10-pin header DIO1
Front panel connector 14-pin header F_PANEL1
IDE connector 40-pin box header IDE1
Infrared connector 5-pin header IR1
Memory slot 240-pin DDR3 DIMM slot DIMM1, DIMM2
PCI slots PCI slot PCI1, PCI2,
PCI3, PCI4,
PCI5
PCIe x4 slot PCIe x4 slot PCIE2
PCIe x16 slot PCIe x16 slot PCIE1
PCIe power connector 4-pin connector PCN1
Power connector 24-pin connector PWR2
RS-232 serial port connector 10-pin box header COM3, COM4,
COM5, COM6
RS-232/422/485 serial port connector 14-pin box header COM2
SATA drive connectors 7-pin SATA drive connectors SATA1, SATA2,
SATA3, SATA4
SMBus connector 4-pin wafer CN9
SPDIF connector 5-pin header SPDIF1
