IMBA-G410 ATX Mo th e rb o a rd
P a g e 49
4.4 J u m p e r S e ttin g s
NOTE:
A jumper is a metal bridge used to close
an electrical circuit. It consists of two or
three metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper means removing the plastic clip
from a jumper.
The IMBA-G410 includes some jumpers shown in Table 4-1.
De s c rip tio n La b e l Typ e
AT/ATX power select jumpers JAUTO1,
JAUTO2
2-pin header
Clear CMOS jumper JP1 3-pin header
COM2 function select jumper JP4 6-pin header
CompactFlash® setup JP2 2-pin header
CF voltage select jumper JP_CF1 3-pin header
USB power select jumpers USBPWR1,
USBPWR2
3-pin header
Table 4-1: Jumpers
4.4.1 AT/ATX P o we r S e le c t J u m p e rs
J u m p e r La b e l: J AUTO1, J AUTO2
J u m p e r Typ e : 2-pin header
J u m p e r S e ttin g s : See Table 4-2
