IMB-C2060 microATX Motherboard
Page 56
Setting Description
Closed ATX power (Default)
Open AT power
Table 4-2: AT/ATX Power Mode Jumper Settings
Figure 4-8: AT/ATX Power Mode Jumper Location
4.3.2 Clear CMOS Jumper
Jumper Label: J_CMOS2
Jumper Type: 3-pin header
Jumper Settings: See Table 4-3
Jumper Location: See Figure 4-9
To reset the BIOS, move the jumper to the "Clear BIOS" position for 3 seconds or more,
and then move back to the default position.
Setting Description
Short 1-2 Normal (Default)
Short 2-3 Clear BIOS
Table 4-3: Clear BIOS Jumper Settings
