IMB-C2060 microATX Motherboard
Page 33
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
33 NRXD6 34 NRTS6#
35 NTXD6 36 NCTS6#
37 NDTR6# 38 NRI6#
39 GND 40 GND
Table 3-18: COM3~6 Serial Port Connector Pinouts
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NDCD7# 2 NDSR7#
3 NRXD7 4 NRTS7#
5 NTXD7 6 NCTS7#
7 NDTR7# 8 NRI7#
9 GND 10 GND
11 NDCD8# 12 NDSR8#
13 NRXD8 14 NRTS8#
15 NTXD8 16 NCTS8#
17 NDTR8# 18 NRI8#
19 GND 20 GND
21 NDCD9# 22 NDSR9#
23 NRXD9 24 NRTS9#
25 NTXD9 26 NCTS9#
27 NDTR9# 28 NRI9#
29 GND 30 GND
31 NDCD10# 32 NDSR10#
33 NRXD10 34 NRTS10#
35 NTXD10 36 NCTS10#
37 NDTR10# 38 NRI10#
39 GND 40 GND
Table 3-19: COM7~10 Serial Port Connector Pinouts
