Temperature1
Sets the target temperature sensor to the System
Temperature1 setting.
Î
System
Temperature2
Sets the target temperature sensor to the System
Temperature2 setting.
Î Temperature Bound n
Use the + or – key to change the fan Temperature Bound n value. Enter a decimal
number between 0 and 127.
Î Segment 1 Speed (PWM)
Use the + or – key to change the fan Segment 1 Speed value in Pulse Width Modulation
(PWM). Enter a decimal number between 0 and 100.
5.3.9 Secondary Super IO Configuration
The Secondary Super IO Configuration (BIOS Menu 15) displays IO chip type and the
submenus for configuring the external SATA ports 7, 8, 9, and 10.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Secondary Super IO Configuration
Super IO Chip Fintek F81216
> Serial Port 7 Configuration
> Serial Port 8 Configuration
> Serial Port 9 Configuration
>
Serial Port 10 Configuration
Set Parameters of Serial
Port 7 (COMG)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Secondary Super IO Configuration
