IMB-C2060 microATX Motherboard
Page 15
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
ATX Power connector 24-pin ATX ATX
Battery connector Battery holder BAT1
CPU fan 4-pin wafer CPU_FAN
CPU power 4-pin connector CPU12V1
Digital I/O 26-pin header DIO1
Front panel audio 10-pin header FP_AUDIO
Front panel 14-pin header F_PANEL1
FW programming 8-pin header CN1
Infrared interface 5-pin header IR1
Memory card DIMM slot DIMM1, DIMM2
PCH fan connector 3-pin wafer PCH_FAN1
PCIe power 4-pin connector PCIE_12V1
SATA 3Gb/s drive connector 16-pin SATA
connector
SATA3, SATA 4,
SATA5, SATA 6
SATA 6Gb/s drive connector 7-pin SATA connector SATA1, SATA2
Serial port, RS-422/485 4-pin wafer COM2
Serial port, RS-232 40-pin box headers COM3-6, COM7-10
SMBus connector 4-pin wafer SMBUS_1
SPDIF 5-pin header SPDIF1
SPI connector 8-pin header SPI
System fan connectors 3-pin wafer SYS_FAN1,
SYS_FAN2
TPM connector 20-pin header TPM
