KINO-PV-D5252/D4252 Mini ITX SBC

Page 69

Step 3:

Insert the VGA connector

Once the connectors are properly aligned with the

insert the male connector from the VGA screen into the female connector on the

KINO-PV-D5252/D4252. See Figure 4-19.

Figure 4-19: VGA Connector

Step 4:

Secure the connector. Secure the DB-15 VGA connector from the VGA

monitor to the external interface by tightening the two retention screws on either

side of the connector.

Step 0:

4.10 Software Installation

All the drivers for the KINO-PV-D5252/D4252 are on the CD that came with the system.

To install the drivers, please follow the steps below.

Step 1:

Insert the CD into a CD drive connected to the system.

NOTE:

If the installation program doesn't start automatically:

Click "Start->My Computer->CD Drive->autorun.exe"
