IEI Integration KINO-PV-D4252_D5252 User Manual
Page 48
KINO-PV-D5252/D4252 Mini ITX SBC
Page 34
Figure 3-19: SATA Power Connector Locations
Pin Description
1 +5V
2 GND
Table 3-20: SATA Power Connector Pinouts
CN Label:
SATA_PWR2
CN Type:
4-pin wafer
CN Location:
See Figure 3-20
CN Pinouts:
See Table 3-21
The SATA Power Connector provides power output to the SATA connectors.
