KINO-PV-D5252/D4252 Mini ITX SBC
Page 21
Pin Description
1 GND
2 VCC12
3 FANIN1
4 FANOUT1
Table 3-7: CPU Fan Connector Pinouts
3.2.6 Fan Connector
CN Label:
J4
CN Type:
3-pin header
CN Location:
See Figure 3-7
CN Pinouts:
See Table 3-8
The fan connector attaches to a cooling fan.
Figure 3-7: Fan Connector Location
Pin Description
1 FANIO1
