Step 2:

Align the SO-DIMM with the socket. Align the notch on the memory with the

notch on the memory socket.

Step 3:

Insert the SO-DIMM. Push the memory in at a 20º angle. (See Figure 4-1)

Step 4:

Seat the SO-DIMM. Gently push downwards and the arms clip into place. (See

Figure 4-1)

4.5 CompactFlash® Installation

NOTE:

Both CompactFlash® Type I and Type II cards are supported.

To install the CompactFlash® card, please follow the steps below.

Step 1:

Locate the CF card socket. Locate the CompactFlash® slot.

Step 2:

Align the CF card. Align the CompactFlash® card. The label side should be

facing away from the board. The grooves on the CompactFlash® slot ensure

that the card cannot be inserted the wrong way.

Step 3:

Insert the CF card. Push until the CompactFlash® card is firmly seated in the

slot. See Figure 4-3.
