KINO-PV-D5252/D4252 Mini ITX SBC
Page 86
Auto D
EFAULT
The serial port IO port address and interrupt address
are automatically detected.
IO=2E8h;
IRQ=10
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10
IO=3E8h;
IRQ=10, 11
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ10, 11
IO=2E8h;
IRQ=10, 11
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ10, 11
5.3.6.2 Parallel Port Configuration
Use the Parallel Port Configuration menu (BIOS Menu 9) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port
[Enabled]
Device Settings
IO=378h; IRQ=7
Change Settings
[Auto]
Device Mode
[Printer Mode]
: Select Screen
: Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous
Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Parallel Port Configuration Menu
Parallel Port [Enabled]
Use the Parallel Port option to enable or disable the parallel port.
Disabled
Disable the parallel port
Enabled D
EFAULT
Enable the parallel port
