5.4.1 Host Bridge Configuration
Use the Host Bridge Configuration menu (BIOS Menu 15) to configure the Northbridge
chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
>
Memory Frequency and Timing
>
OnChip VGA Configuration
MMIO Size [AUTO]
Initate Graphic Adapter [IGD]
******* Memory Information *******
Memory Frequency
800 Mhz
Total Memory
2048 MB
DIMM#0 2048
MB
DIMM#1 Not
Present
: Select Screen
: Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous
Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 15: Host Bridge Chipset Configuration
MMIO Size
Use the MMIO Size option to set the MMIO reserve memory size.
AUTO D
EFAULT
1GB
Enables ION graphics controller.
2GB
Enables PCI/PEG graphics controller.
Initate Graphic Adapter [IGD]
Use Initate Graphic Adapter option to select which graphics controller to use as the
primary boot device. Select either an ION graphics controller or a combination of PCI
graphics controller and PCI express (PEG) controller. Configuration options are listed in
the table below:
