KINO-PV-D5252/D4252 Mini ITX SBC
Page 14
3.1.2 Peripheral Interface Connectors
769H
The table below lists all the connectors on the board.
Connector Type Label
12 V Power connector 4-pin connector PWR2
Battery connector 2-pin wafer BAT1
CompactFlash® slot 50-pin header CF1
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector 3-pin header J4
Flash SPI ROM 8-pin header SPI1
Front panel connector 8-pin header F_PANEL1
Keyboard and mouse connector 6-pin wafer KB_MS1
Keypad connector 9-pin wafer KEY1
LVDS1 connector 30-pin crimp LVDS1
LVDS1 Backlight Inverter
connector
5-pin wafer INV1
LVDS2 connector 20-pin crimp LVDS2
LVDS2 Backlight Inverter
connector
5-pin wafer INV2
Parallel port connector 26-pin header LPT1
PCIe Mini card slot PCIe Mini card slot CN2
Serial ATA (SATA) drive connector 7-pin SATA SATA1, SATA2
SATA power connector 2-pin wafer, 4-pin
wafer
SATA_PWR1,
SATA_PWR2
Serial port connector (RS-232) 10-pin header COM5, COM6
Serial port connector (RS-232) 14-pin header COM2
SMBus connector 4-pin wafer CN4
