PCIE-H610 PICMG 1.3 CPU Card
Page 75
Î
IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
Î
IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
Î Device Mode [RS422/485]
Use the Device Mode option to select the serial port mode.
Î
RS422/485 D EFAULT Enables serial port RS-422/485 support.
5.3.7.2.4 Serial Port 6 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled Disable the serial port
Î
Enabled D EFAULT Enable the serial port
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.
Î
IO=2E0h;
IRQ=10
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ10
Î
IO=2C0h;
IRQ=10, 11
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ10, 11
Î
IO=2C8h;
IRQ=10, 11
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ10, 11
