PCIE-H610 PICMG 1.3 CPU Card
Page 3
1.3 Features
Some of the PCIE-H610 motherboard features are listed below:
ƒ PICMG 1.3 full-size graphics grade solution
ƒ LGA1155 CPU socket
ƒ Intel® H61 chipset
ƒ Dual-channel DDR3/DDR3L DIMMs support up to 16.0 GB
ƒ Dual independent display by VGA and DVI-D (DVI model only)
ƒ Two Realtek PCIe Gigabit Ethernet connectors (LAN1 with ASF 2.0 support)
ƒ Four SATA 3Gb/s connectors
ƒ TPM V1.2 hardware security function supported by the TPM module
ƒ High Definition Audio
ƒ RoHS compliant
1.4 Connectors
The connectors on the PCIE-H610 are shown in the figure below.
Figure 1-2: Connectors
