PCIE-H610 PICMG 1.3 CPU Card
Page 8
Specification/Model PCIE-H610
FDD One 34-pin floppy disk drive connector
Front Panel One 14-pin header (power LED, HDD LED, speaker, power button,
reset button)
I2C One 4-pin wafer connector
Infrared One via 5-pin header
Keyboard/Mouse One 6-pin wafer connector
Parallel Port One parallel port via internal 26-pin box header
Serial ATA Four SATA 3Gb/s connectors
Serial Ports Two RS-232 via internal box headers
One RS-422/485 via internal 4-pin wafer connector
SMBus One 4-pin wafer connector
TPM One via 20-pin header
USB Ports Two external USB 2.0 ports on rear IO
Four internal USB 2.0 ports by two pin headers
Four USB 2.0 ports by backplane pin headers via golden fingers
Environmental and Power Specifications
Power Supply 5V/12V, AT/ATX power supported
Power Consumption [email protected] , [email protected], [email protected], [email protected]
(3.40 GHz Intel® Core™ i7-2600K CPU with two 2GB 1333 MHz
DDR3 memory)
Operating Temperature -10ºC ~ 60ºC
Storage Temperature -20ºC ~ 70ºC
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 338 mm x 126 mm
Weight (GW/NW) 1200 g / 420 g
Table 1-2: PCIE-H610 Specifications
