PCIE-H610 PICMG 1.3 CPU Card
Page 7
1.7 Technical Specifications
The PCIE-H610 technical specifications are listed below.
Specification/Model PCIE-H610
Form Factor PICMG 1.3
CPU Supported LGA1155 Intel® Core™ i7/i5/i3/Pentium®/Celeron® CPU
PCH Intel® H61
Memory Two 240-pin 1333/1066 MHz dual-channel unbuffered DDR3/DDR3L
(1.35V) SDRAM DIMMs support (system max. 16.0 GB)
Graphics Engine Intel® HD Graphics 2000/3000
Supports DirectX 10.1 and OpenGL 3.0
Full MPEG2, VC1, AVC Decode
Audio Supports IEI AC-KIT-892HD audio kit
BIOS UEFI BIOS
Ethernet Controllers Dual Realtek RTL8111E PCIe GbE Ethernet controller (LAN1 with
ASF 2.0 support)
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion PCIe signal and PCI signal via golden fingers
Four PCIe x1slots (default BIOS version) or one PCIe x4 slot (update
to special BIOS version) on backplane
I/O Interface Connectors
Audio Connector One internal audio connector (10-pin header)
Digital I/O 8-bit, 4-bit input/4-bit output
Display Output One VGA integrated in the Intel® H61 (rear I/O)
One DVI-D integrated in the Intel® H61 (via 26-pin header to the
DVI-D/USB kit; DVI model only)
Ethernet Two RJ-45 GbE ports
Fan One 4-pin wafer connector
