PCIE-H610 PICMG 1.3 CPU Card
Page 61
The following sections completely describe the configuration options found in the menu
items at the top of the BIOS screen and listed above.
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.4.0 0.03
Compliency UEFI 2.0
Project Version B222AR06.ROM
Build Date and Time 01/02/2012 14:17:42
Memory Information
Total Memory
1024 MB (DDR3 1333)
System Date
[Thu 02/02/2012]
System Time [15:10:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
Î System Overview
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
ƒ BIOS Vendor: Installed BIOS vendor
ƒ Core Version: Current BIOS version
ƒ Project Version: the board version
ƒ Build Date and Time: Date and time the current BIOS version was made
Î Memory Information
The Memory Information lists a brief summary of the on-board memory. The fields in
Memory Information cannot be changed.
ƒ Total Memory: Displays the auto-detected system memory size and type.
