5.4.1 Northbridge Configuration
Use the North Bridge menu (BIOS Menu 19) to configure the Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Memory Information
Total Memory
1024 MB (DDR3 1333)
Memory Slot0
1024 MB (DDR3 1333)
Memory Slot2 0 MB (DDR3 1333)
Initate Graphic Adapter
[PEG(PCI)/IGD]
IGD Memory [64M]
VT-d
[Disabled]
Select which graphics
controller to use as the
primary boot device.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19:Northbridge Chipset Configuration
Î Initiate Graphic Adapter [PEG(PCI)/IGD]
Use the Initiate Graphic Adapter option to select the graphics controller used as the
primary boot device. Select either an integrated graphics controller (IGD) or a combination
of PCI graphics controller, a PCI express (PEG) controller or an IGD. Configuration
options are listed below:
ƒ IGD
ƒ PEG(PCI)/IGD D EFAULT
Î IGD Memory [64M]
Use the IGD Memory option to specify the amount of system memory that can be used by
the internal graphics device.
Î
Disable
Î
32M 32 MB of memory used by internal graphics device
Î
64M D EFAULT 64 MB of memory used by internal graphics device
