background image

PCIE-H610 PICMG 1.3 CPU Card

Page 36

LED Description

LED Description

A on:

linked

blinking: data is being sent/received

B

off: 10 Mb/s

green: 100 Mb/s

orange: 1000 Mb/s

Table 3-24: Connector LEDs

3.3.2 USB Connectors

CN Label:

USB_C1 and USB_C2

CN Type:

USB port

CN Location:

See Figure 3-22

CN Pinouts:

See Table 3-25

The PCIE-H610 has two external USB 2.0 ports. The ports connect to both USB 2.0 and

USB 1.1 devices.

Pin

Description

1

VCC

2

DATA-

3

DATA+

4

GROUND

Table 3-25: USB Port Pinouts

3.3.3 VGA Connector

CN Label:

VGA1

CN Type:

15-pin Female

CN Location:

See Figure 3-22

CN Pinouts:

See Figure 3-24 and Table 3-26
