PCIE-H610 PICMG 1.3 CPU Card
Page 71
5.3.7.1 Floppy Disk Controller Configuration
Use the Floppy Disk Controller Configuration menu (BIOS Menu 12) to configure the
floppy disk controller.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Floppy Disk Controller Configuration
Floppy Disk Controller [Enabled]
Device Settings Reset Required
Change Settings
[Auto]
Device Mode [Read Write]
Enable or Disable Floppy
Disk Controller
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Serial Port n Configuration Menu
Î Floppy Disk Controller [Enabled]
Use the Floppy Disk Controller option to enable or disable the floppy disk controller.
Î
Disabled Floppy disk controller disabled
Î
Enabled D EFAULT Floppy disk controller enabled
Î Change Settings [Auto]
Use the Change Settings option to change the super IO device address and interrupt
address.
Î
Auto D EFAULT The super IO device address and interrupt address
are automatically detected.
Î
IO=3F8h;
IRQ=6;
DMA=2
The super IO device address is 3F8h, interrupt
address is IRQ6 and DMA channel is DMA2
