PCIE-H610 PICMG 1.3 CPU Card
Page 70
keyboard can control the system even when there is no USB driver loaded onto the
system.
Î
Enabled D EFAULT Legacy USB support enabled
Î
Disabled Legacy USB support disabled
5.3.7 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 10) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Fintek F81866
> Floppy Disk Controller Configuration
> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
> Serial Port 6 Configuration
> Parallel Port Configuration
Power Saving Function
[Disabled]
Set Parameters of Floppy
Disk Controller (FDC)
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Super IO Configuration
Î Power Saving Function [Disabled]
Use the Power Saving Function BIOS option to enable or reduce power consumption in
the S5 state. When enabled, the system can only be powered-up using the power button.
Î
Disabled D EFAULT Power Saving Function support disabled
Î
Enabled Power Saving Function support enabled
