PCIE-H610 PICMG 1.3 CPU Card
Page 67
5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
SATA Port0 Not Present
SATA Port1
Not Present
SATA Port4
Not Present
SATA Port5
Not Present
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
ÆÅ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
Î SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
Î
Disabled Disables SATA devices.
Î
IDE Mode D EFAULT Configures SATA devices as normal IDE device.
Î Serial-ATA Controller 0 [Compatible]
Use the Serial-ATA Controller 0 option to configure the serial ATA controller 0.
Î
Disabled Disables the on-board ATA controller.
Î Enhanced Configures the on-board ATA controller to be in
Enhanced mode. In this mode, IDE channels and SATA
channels are separated. This mode supports up to 6
storage devices. Some legacy OS do not support this
mode.
