Navigating the Display Screen
9650-0806-01 Rev. C Propaq MD Operator’s Guide 2–15
Table 2-3. Propaq MD Quick Access Keys
Quick access key Description
Lead Selects the ECG input source for the first waveform trace.
12 lead Displays the 12-lead monitoring screen.
CO
2
Turns CO
2
on and off.
IBP Displays IBP setup and zero buttons.
Analyze Begins the analysis of the patient’s ECG rhythm.
Print Starts or stops a continuous chart print.
More/Back Goes to the next or previous level of quick access keys.
Brightness Changes the brightness setting -- toggles through high contrast
display (white background), color display (black background), and
night vision goggle (NVG) friendly display.
Treatment Displays the current clinical treatment options.
Alarms Displays the Limits option to allow the user to view/set all parameter
alarm limits and the alarm suspend button.
Log Opens the Log Control panel.
Setup Displays the Setup menu to allow the user to configure settings such
as ECG, display/volume, printer, trends, operational checklist, and
supervisor.
Treatment Summary Displays treatment summary cases, which you can print.
Manual Mode Allows user to change from AED Mode to Manual Mode.
Pause Allows user to Pause the rescue cycle .
I, II,
III...
12
IBP
Analyze
R
LOG
Manual
Mode
Pause
