C HAPTER 22 C OMMUNICATIONS
22–2 www.zoll.com 9650-0806-01 Rev. C
The Communications Icon
The communications icon is located to the right of the patient mode in the display screen. It has
five possible states shown the table below. If all connectivity is disabled, no icon is displayed.
You can select the Communications icon to:
• Access the Wireless menu.
• View preconfigured WiFi access points, connection details, paired devices or distribution
lists.
• Set up a temporary WiFi access point or Bluetooth connection.
Use the navigation keys to select the Communications icon.
State Description
Wireless connected Wireless connectivity is active using WiFi, Bluetooth, or USB cellular
modem. For WiFi, this is the normal operating state. For Bluetooth or
cellular modem, this icon appears only when a transmission is
requested.
Wireless not connected Wireless connectivity is inactive. If a WiFi access point is selected, this
icon indicates the selected network cannot connect due to incorrect
configuration or weak/no signal strength. If the unit is configured to use
Bluetooth or cellular modem, the unit will show this icon until a
transmission is requested.
Failed Communications hardware has failed.
Ethernet connected Ethernet connectivity is active.
Ethernet disconnected Ethernet connectivity is present and enabled, but not currently
connected. Wireless connectivity (if installed) is disabled.
No icon All connectivity is disabled.
Communications icon
