CPR Compression Bar Graph
The Propaq MD unit can display a CPR compression bar graph next to the dashboard that is
computed from the CPR sensor signals. This bar graph, representing depth of compression, is
presented on a (AHA/ERC 2005: 0 - 2.1, AHA/ERC 2010: 0 - 2.5) inch displacement scale
with reference markers at (AHA/ERC 2005: 1.5 and 2.0, AHA/ERC 2010: 2.0 and 2.4) inches.
The unit displays a minimum of 12 seconds of compression data at a rate of approximately 133
compressions per minute.
