Defibrillator – ZOLL Propaq MD Rev C User Manual
Page 291
Defibrillator
9650-0806-01 Rev. C
Propaq MD Operator’s Guide
A-7
Figure A-7.
Rectilinear Biphasic Waveform at 50 Joules
Figure A-8.
Rectilinear Biphasic Waveform at 30 Joules
-20
-15
-10
-5
0
5
10
15
20
0
2
4
6
8
10
12
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm
-15
-10
-5
0
5
10
15
0
2
4
6
8
10
12
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm
