Pacer
9650-0806-01 Rev. C Propaq MD Operator’s Guide A-19
Pacer
Type: External transcutaneous pacing
Pacer Rate: 30 to 180 BPM ± 1.5%.
Output Current: 0 to 140 mA ± 5% or 5 mA (whichever is greater)
Modes: Demand and Fixed
Status Indicators:
ECG lead fault, pace marker on monitor and chart, start/stop indicator on
display.
Pulse Type: Rectilinear, constant current
Pulse Width: 40 ms +/-2 ms
CO
2
Range: 0 to 150 mmHg
Accuracy CO
2
:
* At sea level.
** Accuracy applies for breath rates of up to 80 bpm. For breath rates above 80 bpm,
accuracy is 4 mmHg or ±12% of reading whichever is greater, for EtCO
2
values exceeding
18 mmHg. This is tested according to and is compliant with ISO 21647. To achieve the
specified accuracies for breath rates above 60 breaths/minute, the Microstream FilterLine
H Set for Infant/Neonatal must be used. Above 40 C, ± 1mmHg or ± 2.5% (whichever is
greater) has to be added to the tolerance of the accuracy specs.
Drift of Measurement Accuracy: Over any 24-hour period, the accuracy claims listed above
are maintained.
The accuracy specification is maintained to within 4% for the following gas mixtures (all
values are in Vol.%).
Respiration Range: 0 to 149 breaths per minute
Respiration Rate Accuracy:
0 to 70 bpm: ±1 bpm
71 to 120 bpm: ±2 bpm
121 to 149 bpm: ±3 bpm
Flow rate: 50 ml/min -7.5 + 15 ml/min, flow measured by volume.
Total System Response Time: 2.9 seconds typical, 3.9 seconds maximum.
CO
2
Partial Pressure* Accuracy **
0-38 mmHg ± 2 mmHg
39-99 mmHg ± (5% of reading + 0.08% for every 1 mmHg above 38 mmHg)
100-150 mmHg ± (5% of reading + 0.08% for every 1 mmHg above 38 mmHg)
CO
2
N
2
O
2
N
2
O H
2
0 Anesthetic Agents
1.0 to 13 0 to 97.5 0 to 100 0 to 80 Dry to saturated According to EN 21647
