12-7-2 Fig-19100 Pre-Stretch Unit Table
Ref. Part No. Description Qty. Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
DSB-25+
DS-AG-2819C
PMS-5×15
SPW-5
WS-5
1517R-19106
NES-15-24
SF-4×6
SPW-4
WS-4
DS-2819
99601
997SL
D4/6
TS-35
TBRF
PMS-4/25×10
PMS-4×10
SPW-4
WS-4
DS-AG-2819
1517-191022
LL305
1517-191024
DS-VH-40
1517R-191026
Plastics Screw
Casing
M5x15 Round Head Screw
M5 Spring Washer
M5 Plan Washer
Inverter
VFD004E11T
Power Supple
M4×6 Cross Recessed Round Head Screw
M4 Spring Washer
M4 Plan Washer
Bottom Base
Terminal Block Set
Terminal Block
Terminal Block M4/6
Rail TS-35
End Stop TBRF
4/25x10 Round Head Screw
M4x10 Round Head Screw
M4 Spring Washer
M4 Plan Washer
Junction Box
Plastics Hexagon Nut
Junction Box Connect
Plastics Hexagon Nut
Intake
Plastics Hexagon Nut
1
1
4
4
4
1
1
2
2
2
1
1
1
14
1
1
1
3
3
3
3
2
2
2
2
2
