F:\Manual\SM-1517R-110V-100514 14.05.2010. - 80 -
12-6-2 Fig-19000 Pre-Stretch Unit Table (4)
Ref. Part No. Description Qty. Remarks
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
1360
137
138
1380
139
140
141
142
143
144
145
146
1517R-19112
1517R-19113
1517R-19114
1517R-19115
1517R-19116
1517R-19117
1517R-19118
1517R-19119
1517R-19120
1517R-19121
1517R-19121
WS-8
SPW-8
CAP-8x25
FMS-8x20
1517R-19127
6001ZZ
SH-12-525
1517R-19130
1517R-19131
WS-5
SPW-5
HN-5
BH5×30
1517R-19136
1517R-191360
1517R-19137
1517R-19138
1517R-191380
1517R-19139
R32-520-28
1517R-13008
1517R-19142
STW-14
SH-14×88
FMS-8×20
1517R-19146
Bottom Casing for Canister
Upper Casing for Canister
"R" Snap Ring ψ20
Bracket for Pre-stretch Unit
M12 Spring Washer
M12x25 Hexagon Square Head Bolt
Solenoid
Solenoid Set
M6x15 Hexagon Square Head Bolt
M4 Spring Washer
M4x10 Round Head Screw
M8 Plan Washer
M8 Spring Washer
M8x25 Hexagon Square Head Bolt
M8x20 Flat Machine Screw
Stockade Roller Arm（Upper）
6001ZZ Bearing
ψ
12×525L Shaft
Pin
Return Spring
M5 Plan Washer
M5 Spring Washer
M5 Hexagon Nut
M5x30 Hex Socket Head Bolt
ψ
50x530 Roller (Without Rubber)
Roller & Brake Rubber
ψ
50x530 Roller Brake Rubber
ψ 62x530 Roller (Without Rubber)
Roller & Brake Rubber
ψ
62x530 Roller Brake Rubber
ψ 32x520×ψ28 Roller (D x L x d)
ψ 25 Plastics Ball
Stockade Roller Arm（Bottom）
"R" Snap Ring ψ14
ψ
14×88L Shaft
M8x20 Flat Machine Screw
None
1
1
3
1
2
2
1
1
2
4
4
6
6
6
3
1
6
3
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
4
2
3
0
