12-6-2 Fig-19000 Pre-Stretch Unit Table (1)
Ref. Part No. Description Qty. Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
KYCE-CBC-11C
KYCE-CBC-11
WS-5
SPW-5
CAP-5x10
CAP-M5x15
SPW-5
WS-5
1517R-19009
1517R-19010
WS-5
SPW-5
PMS-5x10
1517R-19014
1517R-19015
6903ZZ
S35-11T-20
HSS-6x6
KEY-5x5x20
S35-12T-18-5
CAP-5x15
CAP-8x30
WS-8
BH5x30
HN-5
SPW-5
WS-5
1517R-19028
R-10x12x8
1517R-19030
KEY-5x5x20
HSS-6x6
S35-32T-20-5
1517R-19034
1517R-19035
HSS-6x6
RTW-20 Fix Plates
Electric Cable
M5 Plan Washer
M5 Spring Washer
M5x10 Hexagon Square Head Bolt
M5x15 Hexagon Square Head Bolt
M5 Spring Washer
M5 Plan Washer
10P Spring Electric Cable
Socket XS3 2410-RF
M5 Plan Washer
M5 Spring Washer
M5x10 Round Head Screw
Upper Cover
M10 Screw
6903ZZ Bearing
#35x11T-ψ20 Sprocket
M6x5 Hex Socket Head Set Screw
5×20 Key
#35x12T-ψ18-5 Sprocket
M5x15 Hexagon Square Head Bolt
M8x30 Hexagon Square Head Bolt
M8 Plan Washer
M5x30 Hex Socket Head Bolt
M5Hexagon Nut
M5 Spring Washer
M5 Plan Washer
Tension Spring
Ring ψ10x12xψ8(D x L x d)
Pressing Arm
5×20 Key
M6x5 Hex Socket Head Set Screw
#35×32T-ψ20-5 Sprocket
#35 Chain Link
#35×59L Chain
M6x5 Hex Socket Head Set Screw
"R" Snap Ring ψ20 2
60
4
4
4
2
2
2
1
1
4
4
4
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
1
