F:\Manual\SM-1517R-110V-100514 14.05.2010. - 66 -
12-2-2. Fig-12000 Film-seat Elevator parts table
Ref. Part No. Description Qty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1506-12001
HN-15
SPW-15
WS -15
WS-15
HN-15
1506-12007
STW-15
RTW-32
6002ZZ
1506-12011
1506-12012
1506-12013
CAP-6×25
1506-12015
SPW-６
CAP-6×15
SPW-6
WS-6
1506-12020 Film-set Elevator Base
M15 Hexagon Nut
M15 Hexagon Nut
M15 Plan Washer
M15 Plan Washer
M15 Hexagon Nut
Shaft
"S" Snap Ring ψ15
"R" Snap Ring ψ32
6002ZZ Bearing
Roller
#40 Chain
#40 Chain Link
M5×25 Hexagon Square Head Bolt
M5 Hexagon Nut
M5 Hexagon Nut
M6×15 Hexagon Square Head Bolt
M6 Spring Washer
M6 Plan Washer
Chain Cover 1
8
8
8
8
8
8
16
8
8
8
1
1
2
2
2
2
2
2
1
