F:\Manual\SM-1517R-110V-100514 14.05.2010. - 69 -
12-3-2 Fig-14000 Bottom Plate parts Table (2)
Ref. Part No. Description Qty. Remarks
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
130
1517-14038
CAP-8×15
None
None
6002ZZ
1517-14043
SH-15-110
1517-14045
STW-15
CAP-6×25
1517-14048
S50-85T
1517-14050
1517-14051
CAP-6×20
SPW-6
WS-6
1517-14055
R-25-16-17
PIN-8-50
1517-14058
FMS-12×40
1517-14062
1517-14130
M8×100L Screw
M8×15 Hexagon Square Head Bolt
None
None
6002ZZ Bearing
Roller
ψ
15×110 Shaft
ψ 23×1.2×ψ15 Washer (D × W × d)
"S" Snap Ring ψ15
M6×25 Hexagon Square Head Bolt
Roller Seat
#50×85T Sprocket
#50 Chain Link
#50×216L Chain
M6×20 Hexagon Square Head Bolt
M6 Spring Washer
M6 Plan Washer
Proximity Switch Sense Bar
Ring ψ25x16xψ17 (D x L x d)
8×50 Pin
ψ
1500 Turntable
M12x40 Flat Machine Screw
Ring Bolt
Roller Unit
1
2
0
0
2
1
1
2
2
12
6
1
1
1
1
1
1
1
4
1
1
4
2
6
