12-1-2. Fig-1100 Pillar parts table (2)
Ref. Part No. Description Qty Remarks
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74 1506-11038
1506-11039
SPW-8
HN-8
1517-11042
1517-11043
1517-11044
1517-11045
RTW-37
HN-8
SPW-8
HSS-6 x 6
6904ZZ
6904ZZ
1506-11052
CAP-8 x 16
SPW-8
WS-8
WS-8
SPW-8
CAP-8 x 16
ATM-2
STW-14
1506-11061
1506-11062
1506-11063
1506-11064
TZ-8108
1506-11066
BH-5x12
BH-5×10
SPW-5
WS-5
TZ-8104
1506-11072
HSS-6 x 16
WS-5 #40 Chain Link
Bracket
M8 Spring Washer
M8 Hexagon Nut
M8 x 75L Screw
Ring 38 x 15 x 20 (D x W x d)
Ring 32 x 15 x 20 (D x W x d)
Shaft ψ20-265
"R" Snap Ring ψ37
M8 Hexagon Nut
M8 Spring Washer
M6 x 6 Hex Socket Head Set Screw
6904ZZ Bearing
#40 x 17T xψ37 Sprocket
None
M8 x 16 Hexagon Square Head Bolt
M8 Spring Washer
M8 Plan Washer
M8 Plan Washer
M8 Spring Washer
M8 x 16 Hexagon Square Head Bolt
ATM-2 TIE MOUNTS
"S" Snap Ring ψ14
Shaft-14- 90L
None
None
None
Limit Switch TZ8104, 5A 250V AC
Switch Bracket
M5×12 Hex Socket Head Bolt
M5×10 Cross Recessed Round Head Screw
M5 Spring Washer
M5 Plan Washer
Limit Switch TZ8104, 5A 250V AC
Switch Plate
M6 x 16 Hex Socket Head Set Screw
M5 Plan Washer 1
2
4
4
2
2
2
1
1
2
2
2
1
1
1
2
2
2
2
2
2
1
4
2
0
0
0
2
2
4
4
4
4
1
1
1
2
