10-2 EMC Component List
Item Name Specification Refer to ckt. diagram Approved document
1 MOTOR1 3~ 0.75KW AC220V SM-1517R: P.1
2 MOTOR2 3~ 0.2KW AC220V SM-1517R: P.1
3 MOTOR3 3~ 0.2KW AC
220V SM-1517R: P.5
4 LINE FILTER 20SS4-1BC2-B
20A AC250V
SM-1517R: P.1 EMC-P.1
5 INVERTER1 VFD007E-11A
0.75KW AC 115V SM-1517R: P.1 EMC-P.2
6 INVERTER2 VFD004E-11A
0.4KW AC 115V SM-1517R: P.1 EMC-P.2
7 INVERTER3 VFD004E-11A
0.4KW AC 115V SM-1517R: P.5 EMC-P.2
9 SWITCHING POWER
SUPPLY
PD-25A DC5V SM-1517R: P.1 EMC-P.5
10 SWITCHING POWER
SUPPLY
PS-65-24 DC24V
2.7A SM-1517R: P.1 EMC-P.5
11 MAIN POWER
SWITCH
OT25E3 Ith=32A
AC 250V SM-1517R: P.1 EMC-P.6
12 PC BOARD KS-050201-MB SM-1517R: P.2, P.3 EMC-P.7
13 PC BPARD KS-050202-KEY SM-1517R: P.2 ,P.3,P4 EMC-P.7
14 PC BPARD KS-050203-TB SM-1517R: P.5 EMC-P.7
15 SWITCHING POWER
SUPPLY
NES-15-24 DC 24V
0.7A SM-1517R: P.5, P.7 EMC-P.8
16 FAN 3-115S
115VAC 0.07A SM-1517R: P.1 EMC-P.10
17 PROXIMITY
SENSOR
TP-SM5N1 DC30V
SM-1517R: P.7 EMC-P.11
