Vestil SWA-60-AW User Manual
Page 55
F:\Manual\SM-1517R-110V-100514
14.05.2010.
- 53 -
11-4 Film-seat doesn’t stop when reached package limit
Check if Photo switch PH is working.
NO
Replace PC board KS-050201-MB
YES
Refer to 3-1,check if Brake BK2 is
working.
YES
Replace Brake Bk2.
NO
Replace PC board KS-050201-MB
11-5 Film-seat doesn’t pause
Check if Relay RYBK2 on PC board
KS-050201-MB, LED M2, MU and LED MD
on PC board KS-050202-KEY is not working.
(LED M2, MU and MD are dark on PC board
KS-050202-KEY and Pause indicator should
light up on operation panel if working).
NO
Replace PC board KS-050201-MB.
YES
Refer to 3-1,Brake BK2, check if Brake
BK2 is Normal.
