Motion Indication:
For detail, refer section
5-5 .
Turntable Speed Adjuster:
Turntable speed can be adjusted between 0-13rpm. This function should be used in conjunction
with the Film-seat Speed Adjuster, refer to Film-seat Speed Adjuster section for more detail.
Film-seat Speed Adjuster:
Film-seat speed can be adjusted between 0~3m/min, either quicken or slower film-seat elevation
speed for desired level of film overlap. When wrapping a test package, adjust turntable speed to
maximum 13rpm and film-seat to maximum 3m/min, then when wrapping completes study the level
of film overlap for further adjustment. If a higher level of film overlap is desired, slower the
film-seat speed; if a lower level of film overlap is desired, slower the turntable speed.
Power Switch:
Main power switch with a safety device. When switch is turned "ON", the switch will jam the
control panel door and prevent it from being opened to provide safety. Please note that if the control
panel door is to be opened this switch must be turned "OFF", or else if the door is forced open when
switch is at "ON" position, the switch will break. If the power switch is broken in such a manner, it
can not be replaced free of charge even if still under warranty.
Emergency Stop Button:
In case of emergency, press this button to stop the operation of the machine and the power will
automatically be turned off. Pull this button to deactivate the emergency stop.
Pre-stretch Unit Ascent Key:
This key is used to manually control the pre-stretch unit to ascent while the machine has stopped.
Press this key; the pre-stretch unit will go up. Release it, the pre-stretch unit will stop immediately.
Pre-stretch Unit Descent Key:
This key is used to manually control the pre-stretch unit to descent while the machine has stopped.
Press this key; the pre-stretch unit will go down. Release it; the pre-stretch unit will stop
immediately.
