F:\Manual\SM-1517R-110V-100514 14.05.2010. - 28 -
10 Electrical
10-1 Part list of electrical components
Item
designation
Description &
function
Manufacture Type Technical data Complies with the
following standards
Marking of
conformity granted
SP1 Switching power
supply, supply dc
power to controller
Mean Well PD-25A Ue=240VAC
OUT1:DC5V 2.1A
OUT2:DC12V1.2A EN61000-4-5,EN60950 CE,TUV
SP2 Switching power
supply, supply dc
power to sps1
Mean Well NES-15-24 Ue=240VAC
OUT:DC 24V 1A EN60950,EN61000-4-5 CE
SP3 Switching power
supply, supply dc
power to brake
Mean Well PS-65-24 Ue=240VAC
OUT:DC 24V 2.7A EN60950,EN61000-4-5 CE
KS-050201-MB Controller Kai Shun KS-050201-MB DC-5V
6MHZ EN61000-4-5
ENV50204 CE
KS-050202-KEY Key board pcb Kai Shun KS-050202-KEY DC-5V EN61000-4-5
ENV50204 CE
KS-050203-TB Terminal block pcb Kai Shun KS-050203-TB DC-5V,12V,24V EN61000-4-5
ENV50204 CE
MPSW1 Power switch ABB OT25E3 Ue=750VAC
Ith=32A
AC-23A=20A EN60204
IEC 947/1,3
IEC60947 CE
LF Line filter Hi & Lo 20SS4-1BC2-B Ue=250VAC
Ith=20A E134751 CE
