Chapter 4: Software Overview Summit User Manual
50
Teledyne LeCroy
Hide Training Sequence. Hide Downstream traffic/recording.
Hide SKIP and Update FC
packets. Advanced Hiding Options
Opens a dialog box that allows you to select
items to hide from view.
Hide Upstream recording/traffic. Compact View
Toggles compacting of training sequences to
analyze
CATC Trace data faster, or no
compacting to display more data.
Find
Opens a dialog box that allows you
to select one or more items to find
in the recording, then searches to
that point. Find Next. Repeats last Find or Search action.
View Packet Level data.
View Link Transaction Level data. View Split Transaction Level data
File Information
Lists the conditions under which
the recording was made. Bus Utilization
Opens a window that graphically represents
various information about the recording.
Error Report
Opens a window that lists all errors
identified in the recording. Link Tracker
Opens a window that displays symbol information
per lane.
Traffic Summary
Opens a window that lists all
events that occurred during the
recording Opens the Data Flow window.
Shows recorded data in a compressed tabular
format.
Navigator. Shows/hides the
Navigator bar - a utility that lets you
easily navigate the CATC Trace. LTSSM Flow Graph 
Shows a state diagram of the LinkTraining
and Status State machine.
