B-500-MTRX-230-8x8 Installation Manual
Pg. 27
www.snapav.com Support: 866.838.5052
15. Specifications
16. Warranty
2
year
2 Year Limited Warranty
This SnapAV
® product has a 2-year Limited Warranty. This warranty includes parts and labor repairs
on all components found to be defective in material or workmanship under normal conditions of use.
This warranty shall not apply to products which have been abused, modified or disassembled.
Products to be repaired under this warranty must be returned to SnapAV or a designated service
center with prior notification and an assigned return authorization number (RA).
TECHNICAL
HDMI Compliance HDMI 3D
HDCP Compliance Yes
Video Bandwidth 6.75Gbps
HDMI over UTP Transmission
Resolution Cat5e/ Cat6 Cat6a
1080i / 720p 24-bit color 200ft 230ft
Full HD 1080P 24-bit color 200ft 230ft
Full HD 1080P 36-bit deep color 200ft 230ft
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection
(1) Human body model — ±15kV (air-gap discharge) & ±8kV (contact
discharge) (2) Core chipset — ±8kV
IR Signal (Bi-directional) Carrier frequency: 20-60kHz
CONNECTIONS
HDBaseT Link 8x RJ45
HDMI 16x HDMI Type A (19-pin female)
IR (In) 1x3.5mm Mono
All IR (Out) 1x3.5mm Mono
IR Input to Room 8x 3.5mm Mono
IR Output to Source 8x3.5mm Mono
RS232 Control Port DB9
Power Latch-Locking
Ethernet 1xRJ45
MECHANICAL
Housing Metal enclosure
Dimensions (W x H x D) 17.32” x 3.46” x 12.60” (without ears)
Weight 11.56 lbs.
Power Supply 24V DC 5A
Power Consumption 50w
Operation Temperature 32~104°F
Storage Temperature -4~140°F
Relative Humidity 20~90% RH (no condensation)
Certifications and Compliance
Product: CE, FCC, Rohs
Power Supply: CE, FCC, Rohs, UL
