B-500-MTRX-230-8x8 Installation Manual
Pg. 19
www.snapav.com Support: 866.838.5052
8.5.2. How to Learn EDID to All Input
--
FF
Example: Input=All EDID Learned from Output 4 Display Readout (Example)
1. Press LEARN L
.
-
.
2. Press OUTPUT L-
3. Press Number Key (1-8) to select the Output the EDID
is learned from
4
4. Press ENTER
(success)
(fail)
8.6. Viewing Input EDID Status
If there is a question about the EDID set for an input, the status of that input’s EDID can be reviewed using the
included IR remote and watching the matrix switcher front panel display.
Notes about EDID Status
• If the EDID was learned from an output, the exact EDID specifications will not be shown, but the output number
will be identified. Review the specifications of the display attached to the output to determine its compatible
resolutions.
• If the second digit (the Input being queried) has a dot after it, then the first digit is the EDID number from the
Embedded EDID table.
• If the second digit (the Input being queried) does not have a dot after it, the first digit is the Output the EDID was
learned from (step 4 from example above).
Example: View the EDID for Input 3.
Display Readout (Example)
EDID 5 Assigned
from Embedded
EDID Table
EDID Learned
from Output 4
1. Press STATUS
-- --
2. Press INPUT
-- --
3. Press Number Key (1-8)to select the desired Input -3 -3
4. Press ENTER 5
.
3
.
4
.
3
