Function Group 1: Run/Stop Mode
Function
No. Description Range/Code
Factory
Setting
User
Setting
1.00 * Run/Stop-Forward/Reverse Control (1)
0000: Keypad
0001: External Contacts
0002: Communication (2)
0001
1.01 * Forward/Reverse Control
0000: Instant Reverse
0001: Stop Command Must be Given
Prior
to Reverse Command
0002: Reverse Command Disabled
0003: Forward Command Disabled
0000
1.02 * Motor Direction
0000: Forward
0001: Reverse
0000
1.03 * Start Command
0000: Accelerates to Last Set
Frequency
0001: Accelerates to Lower
Frequency Limit (See 3.01)
0000
1.04 * Restart Mode
0000: Spin Start
0001: Stop before Restart
0000
1.05 * Auto/Manual Start Mode
0000: Manual Start Mode
0001: Manual Start with Ride-Through
(Set
by 1.06)
0002: Auto Start After Undervoltage
Fault
Clears
0003: Auto Start All Faults
(Except
I 2 t, I•t, and Short Circuit
Faults)
0004: Auto Start All Faults
(Except Short Circuit Fault)
(3)
0000
1.06 * Ride-Through Time (Seconds) 0.0 – 2.0 0.5
1.07 * Number of Restart Attempts 0 – 10 3
1.08 * Start Delay Time (Seconds) 0 – 240 0
1.09 * Stop Mode
0000: Regenerate-to-Stop
0001: Coast-to-Stop
0002: Regeneration with Injection
Brake-to-Stop
(Set by 1.11 – 1.13)
0000
1.10 * Holding Torque in Stop Mode (%) 0 – 10 0
1.11 Injection Brake Start Frequency (Hz) 0.00 – 240.0 0.00
1.12 Injection Brake Level (%) 0 – 30 0
1.13 Injection Brake Time (Seconds) 0.0 – 25.5 0.0
Notes: (1) Sets the source for the Run/Stop-Fwd/Rev in Remote mode (see Function 2.03).
(2) DIDF Option Board required. (3) For Auto Start, Function 1.07 must be set to greater than "0"
(factory setting is "3").
*Functions which can only be changed while the drive is in the Stop Mode.
